The video SFP (emSFP) EB12LCRT-MM-P13D is a short reach optic video SFP (emSFP) .
This SFP (emSFP) is equipped with a 1310nm DFB laser for 12G application allowing the best Extension ratio in the industry.
This SFP (emSFP) is designed to receive one SDI signal (12G/6G-SDI/3G-SDI/HD-SDI/SD-SDI) over single mode fiber (9um/125um) via LC connector.
The optical receiver inside is SMPTE compliant video.

Highlights:

+ SMPTE ST-297-2015, ST2081 and ST2082 compliant
+ Supports 12G, 6G, 3G, HD, SD-SDI and DVB-ASI
+ Operating temperature from -5C to +85C
+ Extinction ratio higher than 8 dBm over temperature in accordance to ST297-2015, specification requires a minimum of 7 dBm
+ Distance up to 20 km with EB12LCRT-MM-P13D-PA (tested with 12G-SDI pathological signal )
+ Distance up to 30 km with EB12LCRT-MM-P13D-PA (tested with 12G-SDI colorbar signal )
+ Sensitivity better than -14 dBm with EB12LCRT-MM-P (tested with 12G-SDI colorbar signal)
+ Sensitivity better than -13 dBm with EB12LC2R-MM-P-PA (tested with 12G-SDI pathological signal)
