DVB/ASI to IP 2022-1/2 De-Encapsulator, Dual Sender, 1GE host

The IP to DVB/ASI Gateway converts two IP ST2022-1/2 into DVB/ASI signals. The miniature plugin device (SFP+) is installed inside the IP switch configured in 1GE which provides a very effective space advantage.

The DVB/ASI to IP conversion option can also be installed on the emFUSION standalone converter platform.

  • Up to 96 Gateways inside a single RU space
  • FEC support
  • 188 & 204 bytes size support
  • Modularity of Gateway process by one channel
  • Future-proof format flexible agility
  • Free emSET configuration and control software
  • Simple Restful API for third party control system
  • High-density and future-proof architecture
  • Simplifies your transition to IP
  • Let you use Commercial Off the Shelf IP switches
  • Important savings in space and cost
  • Future-proof format flexible agility
  • Low power consumption
  • Unmatched integration
  • Simplified setup and control
  • Platform:
  • EB22HDRT-LM-0416 Software Defined emSFP (2x Receiver), MSA, HD-BNC - 1GE IP host
  • Software option:
  • emOPT-2D-ASI IP to DVB-ASI De-encapsulation Option (Dual channels)
  • Cables/Adaptors:
  • EB00CA02-24A HD-BNC Plug (M) to BNC Jack (F) Cable adaptor, 24 in Belden 1855A
  • EB00CA03-36A HD-BNC Plug (M) to BNC Jack (M) Cable adaptor, 36 in Belden 1855A
  • EB00CB02-04A HD-BNC Plug (M) to BNC Jack (F) Cable Assembly, 4 Feet, Belden 1855A
  • EB00CA10-03A HD-BNC Plug (M) to BNC Jack (F) Cable adaptor, 3 in Belden 1855A
  • EB00CA10-36A 12G capable HD-BNC Plug (M) to BNC Jack (F) Cable adaptor, 36 in Belden 1855A

BLOCK DIAGRAM

OBSOLETE144 Block Diagram
